Model 8640B TM 9-4935-601-14-7&P
Table 1-2.- Recommended Test Equipment (6 of 7)
Instrument Type Critical Specifications Suggested Model Use*
Audio Spectrum Tracking Generator:
Analyzer (Cont'd) Flatness: ±0.25 dB
Level: >3 Vrms into 600µ
Spectrum Analyzer Range: 0.5 - 1200 MHz HP 141T/ P,A
Amplitude Calibration: 8552B/8554B
Display Accuracy: ±0.25 dB/dB
but not more than 1.5 dB over
70 dB dynamic range
Flatness: ±1 dB
IF Gain Step Accuracy: ±0.2 dB
Vertical Reference Scale: 10 dB/
division log, 2 dB/division (or
less) log, and linear display cali-
bration
Average Noise Level: <-102 dBm
with 10 kHz IF bandwidth
Spurious Responses: >60 dB down
for inputs of -40 dBm or less
Span Width: 0 - 1 GHz
Compatible with Tracking Generator
Spectrum Analyzer Range: 0.45 -100 MHz HP 141T/ P,A
IF Bandwidths: down to 10 Hz 8552B/8553B
All other specifications are the same
as the HP 141T/8552B/8554B
listed above except Span Width
which should be 0 - 100 MHz
(should be compatible with
Tracking Generator).
Recorder (Strip Compatible with Digital to Analog HP 680 P
Chart) Converter
Accuracy: 0.5% of full scale
Temperature Controlled Range: 0 - 55°C Statham P
Chamber Model 325
Test Oscillator Range: 20 Hz to 600 kHz HP 652A P,A,T
Output Impedance: 600Ω and 50Ω
Distortion: >40 dB down
Output Level: >1 Vrms
*P = Performance; A = Adjustments; T = Troubleshooting
1-18
