Model 8640B TM 9-4935-601-14-7&P
OPERATOR'S CHECKS
RANGE MHz FREQUENCY MHz
0.5-1 0.75000
1-2 01.5000
2-4 03.0000
4-8 06.0000
8-16 12.0000
16-32 024.000
32-64 048.000
64-128 096.000
128-256 0192.00
256-512 0384.00
512-1024 0768.00
Phase Lock
f. Set RANGE 13 to 256-512 MHz. Note that the right-hand digit on the FREQUENCY display 6 flickers between two
digits. Set COUNTER MODE LOCK 5 to ON; the flickering should stop. Slowly adjust FINE TUNE; the
FREQUENCY reading should not change. Adjust FREQUENCY TUNE 12 ; the FREQUENCY display should flash at
about a 2 Hz rate and the reading should change (the reading should follow FREQUENCY TUNE).
RF Output
g. Set COUNTER MODE LOCK 5 to OFF and Source 5 to EXT 0-550. Adjust FREQUENCY TUNE 12 until
FREQUENCY 6 reads 0384.00 MHz. Step through the ranges as specified in step e, setting the COUNTER MODE
EXPAND and Source (EXT) controls 5 to obtain appropriate resolution; FREQUENCY should read approximately as
shown in step e.
NOTE
With RANGE set to 512-1024 MHz, FREQUENCY will read approximately 0384.00 MHz (the actual
frequency at RF OUTPUT).
Meter
h. Set OUTPUT LEVEL 10 to 500 mVOLTS; the meter 3 should indicate 5 on the 0-10 SCALE (the 0-10 SCALE
annunciator 2 should be lit).
Figure 3-4. Operator's Checks (3 of 5)
