B-2 Preliminary November 4, 1998 MAX 4000 Series Hardware Installation Guide
MAX Technical Specifications
Power requirements
Power requirements
Table B-1 describes the ac source power requirements for the MAX 6000.
Table B-2 describes the dc power requirements for the MAX 6000.
The MAX stores its configuration profiles in battery-protected memory. When you power off
the MAX, the profiles remain in tact.
Note: Use a protected ac power source, or add surge protection between the power source and
the MAX.
Environmental requirements
For best results, you should house the MAX in a room with constant temperature and humidity.
In general, cooler environments are better. An operating temperature of 32° to 104° Fahrenheit
(0° to 40° Celsius) is recommended. Storage temperatures of -40° to 176° Fahrenheit (-71.4° to
80° Celsius) are acceptable.
Humidity should be high enough to prevent accumulation of static electricity, but low enough
to prevent condensation. An operating relative humidity of up to 90% is acceptable.
You can operate the MAX at altitudes of 0 to 14800 ft. (0-4500 m).
Table B-1. MAX 4000 ac source power requirements
Element Value
Input Voltage 100-240 Vac
Input Power 450W maximum
Fuse 250 V, 6.3 A, Type T, 5 x 20 mm
Frequency 50/60 Hz
Current 5 A
Table B-2. MAX 6000 dc source power requirements
Element Value
Voltage 100-240 Vac
Phase Single
Frequency 50/60 Hz
Power MAX 4000/4002/4004: 80W (nominal)-200W
(maximum)
Standard MAX: 80W (nominal)-120W (maximum)
