MAX 4000 Series Hardware Installation Guide Preliminary November 4, 1998 C-1
C
Cables and Connectors
This appendix describes specifications for different facets of the MAX, and discusses cabling
requirements. This appendix covers the following topics:
User interface specifications
The interface for the control-monitor, palmtop-controller, and MIF each has its own cabling
pinout specifications. The MAX supports control-monitor, palmtop-controller, and MIF
interfaces.
Control port and cabling pinouts for the control-monitor and MIF
The control-port uses a standard DE-9 female connector that conforms to the EIA RS-232
standard for serial interfaces. Table C-1 applies to all MAX models that use the RS-232
pinouts.
User interface specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-1
Ethernet interface specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-4
T1/PRI interface specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-4
E1/PRI interface specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-13
ISDN BRI interface specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-20
Serial host interface specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-21
Serial WAN cabling specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-41
IDSL specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-43
Table C-1.Control-monitor and MIF control-port and cabling pinouts
DE-9 pin number RS-232 signal name Function I/O
1 DCD Data Carrier Detect O
2 RD Serial Receive Data O
3 SD Serial Transmit Data I
4 DTR Data Terminal
Ready
I
