Ascend T1 MAX series - Setting up the Hardware; Figure 2-4 Dimensions of the Single Power Supply Unit; Figure 2-5 Dimensions of the Redundant Power Supply Unit

Setting Up and Testing the MAX Hardware
Setting up the hardware
MAX 4000 Series Hardware Installation Guide Preliminary November 4, 1998 2-5
Setting up the hardware
Before you set up the MAX hardware, you need to make sure you have the appropriate space.
You can install the MAX in a 19-inch or 23-inch rack.
The following illustrations show the dimensions of both base MAX units: the single power
supply unit and the redundant power supply unit.
Figure 2-4. Dimensions of the single power supply unit
Figure 2-5. Dimensions of the redundant power supply unit
