MAX Technical Specifications
Alarm relay operating specifications
MAX 4000 Series Hardware Installation Guide Preliminary November 4, 1998 B-3
The MAX base system weighs 15 lbs (6.81 kg). A fully loaded system weighs 30 lbs (13.6 kg).
The MAX has these dimensions: 3.0" x 17" x 12” (8.9 cm x 43.2 cm x 30.5 cm).
The base system of a redundant power standard MAX or MAX 6000 weighs 41 lbs (18.6 kg); a
fully loaded system weighs 56 lbs (25.5 kg). The redundant power MAX has the dimensions
7.0" x 17.5" x 14.75" (17.8 cm x 44.5 cm x 36.875 cm).
Alarm relay operating specifications
On the back panel of the Ascend unit is a pair of alarm-relay terminal-block contacts that
remain open during normal operation. The contacts close during loss of power, hardware
failure, or reset.
The maximum rated load for the alarm relay is:
1 amp at 30 Vdc
0.6 amp at 60 Vdc
0.6 amp at 60 Vac
!
Caution: To reduce the risk of electric shock, do not connect the alarm circuit to a device
with an output exceeding 30 Vrms, 42.4 Vpeak, or 60 Vdc.
