Getting Acquainted with the MAX
The items in your MAX package
MAX 4000 Series Hardware Installation Guide Preliminary November 4, 1998 1-3
Checking other package contents
After you verify that you have received the correct base unit, make sure your package contains
the following items:
• A console cable (null-modem)
• Two adapters
• A power cable
• A rack-mounting kit
• Separately packaged expansion modules, (if you ordered them separately)
If you are missing any items, contact your MAX distributor.
Checking the expansion cards
The MAX accommodates up to six expansion cards (also referred to as expansion modules or
slot cards). The figures in this section will help you to identify your expansion cards.
Host/6 card
The Host/6 card (Figure 1-4), also known as the AIM/6 card, supports six V.35 host ports. A
Host/6 card supports 32 active channels. You can install a maximum of two Host/6 cards in the
MAX.
Figure 1-4. Host/6 card
