Cables and Connectors
Serial host interface specifications
MAX 4000 Series Hardware Installation Guide Preliminary November 4, 1998 C-27
V.35/RS-366 cable to generic serial host
The V.35/RS-366 cable connects the MAX to the V.35 ports of a wide variety of equipment
that uses RS-366 dialing. A female-to-male V.35 gender changer is included when you order
the cable. Figure C-15 and Table C-22 show the V.35/RS-366 cable pinouts.
Figure C-15. V.35/RS-366 cable to generic serial host
Table C-22. Pinouts for V.35/RS-366 cable to generic serial host
Model number MBHD-V35-366
Part number 2510-0077-001
Pair # Signal
(MAX)
MAX male DB-44
(MAX)
Host female V.35 RS-366 female DB-25
1FGND1 A
2SD+
SD-
26
27
P
S
3RD+
RD-
2
3
R
T
4ST+
ST-
4
5
Y
AA
