ASCOM IP-DECT Base Station User Manual

TD 92372GB
2007-06-18/ Ver. E
Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway
6
Figure 5.
Base station LED Description
Not lit No U
PN
link established.
Flashing U
PN
link established (activated state), RFP is not
operational.
Steady RFP is fully initialised and operational.
Figure 6.
Base station LED Description
Not lit No speech activity in RFP.
Flashing All speech channels occupied in RFP.
Steady Speech activity in RFP.
Figure 7.
Sync/Ref sync LED Description
Not lit No sync communication established.
Steady Communication established.
Figure 8.
Sync/Ref sync LED Description
Not lit Sync port not selected as input sync source.
Flashing Sync port selected as input sync source but the
sync signal is not in sync.
Steady Sync port selected as input sync source and the
sync signal is in sync.
Figure 9.
Lan LED Description
Not lit No link.
Flashing Link present and network activity.
Steady Link present, but no network activity.
Figure 10.
Lan LED Description
Not lit 10 Mbps operation.
Steady 100 Mbps operation.
