Appendix B: RFP Power Consumption
The tables below show power consumption for a base station connected to the IPBL. The
power consumption of the IPBL is approximately 15 W.
Note: The maximum cable length for base stations connected to the IPBL must not
exceed 1500 meters.
B.1 KRCNB 201/DCT1800
Figure 65.
Cable
length
(metres)
0.4 mm wire size (∅) 0.5 mm wire size (∅) 0.6 mm wire size (∅)
0 EPP 1 EPP 0 EPP 1 EPP 0 EPP 1 EPP
0 7.5 7.5 7.5 7.5 7.5 7.5
100 7.9 7.8 7.8 7.7 7.7 7.6
200 8.3 8.0 8.0 7.8 7.8 7.7
300 8.9 8.3 8.3 8.0 8.0 7.8
400 9.8 8.7 8.7 8.2 8.2 7.9
500 11.3 9.2 9.2 8.5 8.4 8.0
600 - 9.8 9.8 8.7 8.6 8.2
700 - 10.7 10.7 9.0 8.8 8.3
800 - 12.3 12.3 9.4 9.1 8.4
900 - - - 9.8 9.5 8.6
1000 - - - 10.3 9.9 8.8
1100 - - - 11.1 10.4 8.9
1200 - - - 12.3 11.1 9.1
1300 - - - - 12.1 9.3
1400 - - - - - 9.6
1500 - - - - - 9.9
1600 - - - - - 10.2
1700 - - - - - 10.6
1800 - - - - - 11.1
1900 - - - - - 11.7
2000 - - - - - 12.7
2100 - - - - - -
2200 - - - - - -
2300 - - - - - -
2400 - - - - - -
2500 - - - - - -
2600 - - - - - -
2700 - - - - - -
Table 1 Power consumption (watts) of base stations and cabling when powered with 48 V
