TD 92372GB
2007-06-18/ Ver. E
Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway
25
• HTTP 1.1 protocol
• HTML 4.0 protocol
• XML/XSL Version 1.0
The GUI has been tested with Internet Explorer 6.x, but can also be operated with other
browsers in compliance with the requirements above.
6.2 Access the GUI
The GUI interface is accessed through a standard web browser. It is possible to use the
name, ipbs-xx-xx-xx and ipbl-xx-xx-xx, where xx-xx-xx is the end of the MAC address.
Note: The IPBL name is always ipbl-xx-xx-xx regardless if LAN1 (MAC xx-xx-xx-xx-xx) or
LAN2 (MAC yy-yy-yy-yy-yy) is used.
It is also accessed by entering http://xxx.xxx.xxx.xxx in the browser address field. In this
address, xxx.xxx.xxx.xxx should be replaced with the IP address determined in
6.2.1
Determine the IP Address on page 25.
Access the GUI and change the default password as described in 6.2.2 Change the Default
Password on page 27.
6.2.1 Determine the IP Address
The factory setting of the DHCP mode is "automatic", at first power up it will act as a
DHCP client. If the network has a DHCP server, it will assign an IP address to the IPBS/IPBL.
If there is no DHCP server in the network the IPBS/IPBL can be assigned a predefined IP
address.
Note: After the first startup the DHCP mode should be changed from "automatic" to
either "client" or "off", see
7.2.1 Set DHCP Mode on page 37.
