The term “IC:” before the radio certification number only signifies that industry
of canada technical specification were met.
TD 92372GB
2007-06-18/ Ver. E
Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway
12
Figure 16.
EXPOSURE TO RADIO FREQUENCY SIGNALS
This device complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment. The antenna used for this transmitter must be
installed to provide a separation distance of at least 20 cm from all persons and
must not be co-located or operating in conjunction with any other antenna or
transmitter.
Figure 17.
3.7 CE-marking
The IP-DECT System is CE-marked.
Products marked with the label comply with the following European Council
Directives:
• 99/5/EC, concerning Radio- and Telecommunications Terminal Equipment (RTTE)
• 73/23/EC, concerning Low Voltage Directive (LVD)
• 89/336/EEC, concerning Electromagnetic Compatibility Directive (EMC)
Declarations of Conformity of the products are available at the web page:
www.ascom.com/ws/solutions_ws/products_ws.htm
4 Installation of the Base Station
This section describes how to install the IPBS and BS3x0. Both base stations can be fixed to
a wall, a ceiling, a pole or a beam, by means of the mounting bracket included. When
fixing the base station to a wall or ceiling the included plugs and screws must be used.
When fixing it to a pole or beam a strap or a flexible metal band must be used, this is not
included.
4.1 Base Station Cabling
Recommended base station cable is a standard CAT5 unshielded ethernet cable with
minimum 26 AWG copper conductors, this cable is also used for powering the base
station. It is assumed that installation personnel know how to crimp RJ45 connectors to a
cable.
Note: Since the distance between the base station and the wall is limited, a RJ45 modular
jack without cable retention must be used.
