TD 92372GB
2007-06-18/ Ver. E
Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway
55
7.8 Traffic
Traffic information is displayed in the Traffic sub menu. For the master the traffic
information for the IP-DECT system is displayed as well as traffic information for the radio
itself (if this radio is enabled).
7.8.1 Statistics
The Statistics page shows traffic statistics. If the IPBS/IPBL is a master, statistics for the
whole IP-DECT system is shown under the Master heading. Traffic statistics for the radio
part is shown under the Radio heading. See the table below for information about the
different statistics fields.
Figure 59.
Master
Calls In The number of incoming calls to the system.
Calls In Connected The number of connected incoming calls in the
system.
Calls Out The number of outgoing calls in the system.
Handover The number of handovers in the system.
Handover Failed The number of failed handovers in the system.
Abnormal Call Release The number of abnormal call terminations.
Radio
Calls In The number of incoming calls to the radio.
Calls Out The number of outgoing calls from the radio.
Handover The number of handovers in the radio.
Handover Failed The number of failed handovers in the radio.
7.8.2 Display All Ongoing Calls in the System
All ongoing calls in the IP-DECT system can be displayed by selecting Traffic > Master Calls
in the master.
7.8.3 Display Calls
All ongoing calls on an IPBS/IPBL can be displayed by selecting Traffic > Radio Calls.
7.8.4 Handover
During call, all ongoing handovers in the IP-DECT system can be displayed by selecting
Traffic > Handover in the master.
