ASCOM IP-DECT Base Station User Manual

TD 92372GB
2007-06-18/ Ver. E
Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway
37
7.2 LAN
This section describes how to do the following configurations and settings.
• Set DHCP mode
• Set IP static address
• Set dynamic IP address
• Set link type
• Configure VLAN
• View LAN statistics
Note: The IPBL has two identical LAN connections.
7.2.1 Set DHCP Mode
The IPBS/IPBL can have different DHCP modes, see the table below.
Figure 39.
Off Used if the IPBS/IPBL should have a static IP address.
Client The IPBS/IPBL acts as a DHCP Client, if there is a DHCP server in
the network it will be assigned an IP address
Automatic In automatic DCHCP mode the IPBS/IPBL will act as a DHCP
client on power up.
If the IPBS/IPBL is restarted by shortly pressing the reset button
it will get the IP address 192.168.0.1 and the netmask
255.255.255.0
Change DCHP mode following the steps below.
1 Select LAN > DHCP.
2 Select DHCP mode in the Mode drop-down list.
3 Click “OK”.
4 Reset in order to make the changes take effect, see 7.12 Reset on page 60.
7.2.2 Set a Static IP Address
It is necessary for the master and the standby master to have static IP addresses. The slaves
can have dynamic IP addresses retrieved from the network DHCP server.
Ask the network administrator to reserve an IP address for the master and standby master.
1 Select LAN > DHCP.
2 Select “Off” in the Mode drop-down list.
3 Click “OK”.
4 Select LAN > IP.
5 Enter "IP Address", "Network Mask", "Default Gateway" and "DNS Server"
addresses provided by the network administrator in the text fields.
6 Click “OK”.
7 Reset in order to make the changes take effect, see 7.12 Reset on page 60.
8 Start the web-based configuration, using the static IP address.
