7.7.4 Sync Ring
This section only applies to the IPBL.
A wire map of the synchronization ring is available in the GUI. The identities (IPBL-xx-xx-xx)
of the IPBLs and the position in the ring is displayed. If the ring is broken it is possible to
locate where. Click the IP address to access another IPBL.
1 Select Device Overview > Sync Ring.
Figure 56.
Figure 29. Example on a Sync Ring
7.7.5 Sync Ports
This section only applies to the IPBL.
Displays the current status of the synchronization ports.
1 Select Device Overview > Sync Ports.
Figure 57.
Status The current status of the port.
Sync Offset The synchronization offset for the IPBL.
Cable Delay The delay caused by the cable.
Sync Lost Counter The number of times synchronization lost.
Communication The present status of communication.
Connected to The IP address of the IPBL connected.
Tx Error The number of transmitting errors.
Rx Error The number of receiving errors
Figure 58.
