Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway
39
7.3 IP
7.3.1 Configure IP Settings
The following settings can be done in the IP settings sub menu:
• Set ToS priority.
• Set RTP ports.
1 Select IP > Settings.
2 Enter ToS priority (0..7) in the ToS Priority text field.
3 Select which ports to use for RTP traffic by entering the first port in the First UDP-
RTP Port text field.
4 Enter the number of ports to use in the Number of Ports text field.
Note: If the ports fields are left blank, the ports 16384 to 32767 will be used.
5 Click "OK".
7.3.2 Routing
View the IP routing by Select IP > Routing.
7.4 LDAP
The Lightweight Directory Access Protocol (LDAP) protocol is required for systems in which
the server and a replicating client access a joint user database. All IPBS/IPBLs in the system
have access to the database, one of the IPBS/IPBLs or the VoIP gateway can be configured
to be the LDAP server.
The joint user database contains information about the users registered in the system. It
also contains the system configuration, that is the configurations made under the "DECT"
menu.
This section describes how to do the following configurations and settings.
• Configure LDAP Server
• Check LDAP server Status
• Configure LDAP Replicator
• Check LDAP Replicator Status
7.4.1 Configure LDAP Server
The IP-DECT system needs an LDAP server. If the VoIP gateway is setup as an LDAP server
the master should be setup as an LDAP replicator, see
7.4.2 Configure LDAP Replicator on
page 40.
Setup the IPBS/IPBL as an LDAP server:
Note: The selected user name and password must be the same in both the master and the
standby master.
1 Select LDAP > Server.
2 Add a user, for example ldap-user, in the User text field.
