ASCOM IP-DECT Base Station User Manual

TD 92372GB
2007-06-18/ Ver. E
Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway
70
B.2 BS3x0
Figure 66.
Cable
length
(metres)
0.4 mm wire size (∅) 0.5 mm wire size (∅) 0.6 mm wire size (∅)
0 EPP 1 EPP 0 EPP 1 EPP 0 EPP 1 EPP
0 5.0 5.0 5.0 5.0 5.0 5.0
100 5.2 5.1 5.1 5.1 5.1 5.1
200 5.3 5.2 5.2 5.1 5.1 5.1
300 5.6 5.3 5.3 5.2 5.2 5.1
400 5.8 5.5 5.5 5.3 5.3 5.2
500 6.1 5.6 5.6 5.4 5.4 5.2
600 6.5 5.8 5.8 5.5 5.4 5.3
700 7.1 6.0 6.0 5.6 5.5 5.3
800 8.1 6.2 6.2 5.7 5.6 5.4
900 - 6.5 6.5 5.8 5.7 5.4
1000 - 6.9 6.9 5.9 5.8 5.5
1100 - 7.3 7.3 6.1 5.9 5.6
1200 - 8.1 8.1 6.2 6.1 5.6
1300 - - - 6.4 6.2 5.7
1400 - - - 6.6 6.4 5.8
1500 - - - 6.9 6.6 5.8
1600 - - - 7.2 6.8 5.9
1700 - - - 7.5 7.0 6.0
1800 - - - 8.1 7.3 6.1
1900 - - - 9.6 7.8 6.2
2000 - - - - 8.4 6.3
2100 - - - - - 6.4
2200 - - - - - 6.5
2300 - - - - - 6.6
2400 - - - - - 6.8
2500 - - - - - 6.9
2600 - - - - - 7.1
2700 - - - - - 7.3
2800 - - - - - 7.6
2900 - - - - - 7.9
3000 - - - - - 8.4
3200 - - - - - -
3400 - - - - - -
3600 - - - - - -
3800 - - - - - -
4000 - - - - - -
Table 2 Power consumption (watts) of base stations and cabling when powered with 48 V
