81
7647H–AVR–03/12
Atmel ATmega16/32/64/M1/C1
9.4.9 Port D Input Pins Address – PIND
9.4.10 Port E Data Register – PORTE
9.4.11 Port E Data Direction Register – DDRE
9.4.12 Port E Input Pins Address – PINE
Bit 76543210
PIND7 PIND6 PIND5 PIND4 PIND3 PIND2 PIND1 PIND0 PIND
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value N/A N/A N/A N/A N/A N/A N/A N/A
Bit 76543210
– – – – – PORTE2 PORTE1 PORTE0 PORTE
Read/Write R RRRRR/WR/WR/W
Initial Value00000000
Bit 76543210
– – – – – DDE2 DDE1 DDE0 DDRE
Read/Write R RRRRR/WR/WR/W
Initial Value00000000
Bit 76543210
– – – – – PINE2 PINE1 PINE0 PINE
Read/Write R R R R R R/W R/W R/W
Initial Value00000N/AN/AN/A
