User's Manual 3. Getting Started

23 C450HD IP Phone

Softkey Description

Reject Displayed when the phone rings, alerting to an incoming call. Lets you reject the call.

Accept Displayed when the phone rings, alerting to an incoming call. Lets you accept the call.
