Connecting Internal Cables
Installation Handbook, AutroSafe Interactive Fire Detection System, Release 4, 116-P-ASAFE-INSTALL/DGB Rev. I, 2014-04-01,
Autronica Fire and Security AS
Page 34
8.2.3 Multifunction Serial Port Connection on Controller Board BSA-400
A ribbon cable is connected between the Multifunction Serial Port
Connector and the main terminal block (mounted on the DIN rail inside
the cabinet).
8.2.4 Multifunction Serial Port Connection on Terminal Block, List L1
The ribbon cable from the Serial Port Connection on the Controller
Board is connected to the main terminal block, list L1 (mounted on the
DIN rail inside the cabinet).
Connector J3
Multifunction cable XGE-1/20-40
Multifunction cable
XGE-1/20-40
