Autronica Autro Safe User Manual

Appendix A - Controller Board BSA_400
Installation Handbook, AutroSafe Interactive Fire Detection System, Release 4, 116-P-ASAFE-INSTALL/DGB Rev. I, 2014-04-01,
Autronica Fire and Security AS
Page 70
14.13.3 Schematic of port equivalent:
TX_422_X+
Isolation
TX_422_Z-
RX_422_A+
RX_422_B-
Signal Reference
+5v_SER_0
8
14.14 RS-232 Connections
14.14.1 Ribbon Cable Connector BSA-400 to Terminal Block L1
14.14.2 Switch Setting – Switch S6 and S7
Switch
RS-232
S6.1
Not applicable
S6.2
Not applicable
S6.3
Not applicable
S7.1
Not applicable
S7.2
Not applicable
