Autronica Autro Safe User Manual

Connecting Internal Cables
Installation Handbook, AutroSafe Interactive Fire Detection System, Release 4, 116-P-ASAFE-INSTALL/DGB Rev. I, 2014-04-01,
Autronica Fire and Security AS
Page 35
8.2.5 Multifunction Serial Port Connection Overview – BSA-400
Connection to
terminal block
(L1)
Description
Connector J3 on Controller
Board BSA-400
L1.1
GND
J3.1
L1.2
GND
J3.2
L1.3
AutroFieldBus B
J3.3
L1.4
Multifunction Serial Port RS-422/RS485 A+
J3.4
L1.5
AutroFieldBus B’
J3.5
L1.6
Multifunction Serial Port RS-422/RS485 B-
J3.6
L1.7
AutroFieldBus B Reference
J3.7
L1.8
Multifunction Serial Port RS-422 X+
J3.8
L1.9
AutroFieldBus A
J3.9
L1.10
Multifunction Serial Port RS-422 Z+
J3.10
L1.11
AutroFieldBus A’
J3.11
L1.12
Multifunction Serial Port RS-232 TX
J3.12
L1.13
AutroFieldBus A Reference
J3.13
L1.14
Multifunction Serial Port RS-232 RX
J3. 14
L1.15
GND
J3.15
L1.16
Multifunction Serial Port Reference
J3.16
L1.17
Fault Relay Normal Open
J3.17
L1.18
GND
J3.18
L1.19
Fault Relay Normal Closed
J3.19
L1.20
Fault Relay Common
J3.20
8.3 BC-440
For information on the cabling to AutroSafe Controller Rack BC-440,
refer to separate datasheet.
