Connecting External Cables
Installation Handbook, AutroSafe Interactive Fire Detection System, Release 4, 116-P-ASAFE-INSTALL/DGB Rev. I, 2014-04-01,
Autronica Fire and Security AS
Page 49
9.10 Mains Power Connections
Power must not be applied before commissioning, refer to
Commissioning Handbook.
When applying power during commissioning, always connect the
cables to the batteries in the Power Cabinet BP-405 first, then power
up the system shortly afterwards by connecting the mains cable to a
mains socket (230V/115V AC) or by switching the power ON from an
external main fuse box.
The connection of mains power (AC) to the Power Cabinet BP-405 is
shown below. Note that the isolation must be kept on the mains cable
as close up to the terminal points (L, N and ) as possible.
