Avaya S8100 Series Installing And Configuring

LED indicators
Issue 4.1 June 2005 89
Figure 12: LEDs on back panel of S8710 Media Server
Figure notes:
1. Not used
2. Not used
3. DAL1 fault (AMBER)
4. DAL1 power (GREEN)
5. RJ45 link (GREEN)
6. RJ45 link (GREEN)
7. Active/standby mode (BLUE)
8. Power supply (GREEN)
2
3
iLO
VDCI
1
2
3
133 MGz
100 MGz
100 MGz
UID
2 1
DAL1 DUP MEMORY
RECEIVE MODE
LINC SYNC
TRANS MODE
LINC ACTIVE
msds871c KLC 093004
5 6
2
3
1
2
3
4
7
8
