Testing the media server installation
90 Installing and Configuring the Avaya S8700 Series Media Server
Avaya Ethernet switch LEDs
The C360 series converged, stackable, Ethernet switches include:
● 24-port C363T
● 24-port power over Ethernet C363T-PWR
● 48-port C364T
● 48-port power over Ethernet C364T-PWR
The front panel of these switches has one port LED associated with each port, three system
status LEDs, and seven port function LEDs. The PWR switches have an additional PoE LED.
The port function LEDs are selectable with a set of two left/right buttons. The port LEDs display
the status of the selected function for each port.
The following table lists the system and port function LEDs.
See the documentation shipped with the Ethernet switch for the interpretation of the on/off/
blinking states of the LEDs.
LED Name Description
System LEDs
PWR Power status
SYS System status
ROUT Routing mode
Port Function LEDs
LNK Link status
COL Collision status
Tx Transmit to line
Rx Receive from line
FDX Full Duplex mode
Hspd High speed mode
LAG Link aggregation group for trunking
PoE (PWR
versions only)
Power over Ethernet status
