64 User’s Manual—SNAP™ 700 Printer
Classification: Avery Dennison - Public
17d).
10. Reconnect the two print head cable connectors, making sure that the
connectors are seated tightly.
11. Slide the head mounting plate under the two flat retaining springs until it
clicks into position.
WARNING: If the cables are not connected correctly, the print
head could be destroyed when the power to the printer is
turned on. Check to see that the cable is tight by observing
from underneath the print head. The cable’s connectors should
be inside of the connectors located on the print head.
12. Replace the stock and ink supplies, and double-check your work.
13. Turn on the power to the printer.
14. You must set the printhead category to adjust for variations in the individual
printheads. Using the average resistance value from step 4 above,
determine the printhead category from the table below
15. You may set the head category using the Virtual Control Panel in PCMate
Platinum.
16. Using the Virtual Control Panel in PCMate Platinum, select the COM port to
which the printer is attached, and then click the Show Settings button. Click
on the Options tab and set appropriate head category. Click the Apply
Settings button to return to PCMate Platinum.
17. As a final test, make a test run to check the print quality of the labels.
