Reference
Envision EX5000 -90- 600-00151-001 Rev 01
Once you have downloaded the Nav from your PC to either a Zip Disk
Dataloader or USB Flash Memory Drive, as described in the Avidyne
Data Update Guide, you will need to upload the data to your EX5000.
To load NavData to your EX5000:
1) Bring either the Zip Drive and disk or the USB Flash Memory
Drive to the EX5000 at the aircraft.
2) Turn power OFF to the EX5000.
3) Connect the data source to the EX5000:
n If using a USB Flash Memory Drive, plug it into the data port
on the front of the EX5000.
n If using a Zip Drive Dataloader, put the Zip disk into the Zip
Drive. Connect one end of the cable to the Zip Drive and the
other end to the EX5000 data port.
4) Turn on the master switch to power up the EX5000. The
Dataloader page displays.
5) Press Proceed. Do not turn off the EX5000 or disconnect the
cable during a data load.The data load is complete when the
regular Startup page is displayed.
6) At this point, turn off power to the EX5000, remove your USB
Flash Memory Drive or Zip Drive, and then turn the EX5000
power back on. This step ensures that all data has been checked
in self-test and the MFD is ready for use.
This step ensures that all data has been checked in self-test and the
MFD is ready to use.
Note: Ensure that the Dataloader is supported and not dangling by
the cable. Letting the Dataloader dangle can cause permanent
damage to the data port. It can also cause an intermittent connection,
which will result in an unsuccessful data update
Note: If the regular start screen displays, the EX5000 did not detect
the Zip Drive. Check the connection between the Zip Drive and the
EX5000, then restart the procedure.
