Updating Your Databases
600-00151-001 Rev 01 -91- Envision EX5000
7) Store the Zip Drive and cable or USB Flash Memory Drive in a
safe place.
9.1.2 Loading CMax Chart Data
Once you have downloaded the CMax data from your PC to either a
Zip Disk Dataloader or USB Flash Memory Drive, as described in the
Avidyne Data Update Guide, you will need to upload the data to your
EX5000.
To load CMax Data to your EX5000:
1) With the MFD power OFF:
n If using a USB Flash Memory Drive, plug it into the data port
on the front of the EX5000.
n If using a Zip Drive Dataloader, connect one end of the cable
to the Zip Drive and the other end to the EX5000 data port Do
not insert the Zip disk into the Zip Drive until after you turn on
the MFD (in step 2).
2) Turn on the MFD. If you are using a Zip Drive, insert the Zip disk
into the Zip Drive when the initial Avidyne logo screen is
displayed.
3) The Dataloader page displays.
If this is the first-ever update, you may see a warning that you are
about to load older data than the MFD already contains. This is
because the preloaded demo charts expire in the year 2020, so
the warning message is normal.
Press Proceed to start the chart data load.
4) The Dataloader page shows the progress as it loads the data into
the MFD. After loading the data, the Dataloader performs an
integrity check on the data and displays a successful data load
message if all data is valid.
Note: Ensure that the Dataloader is supported and not dangling by
the cable. Letting the Dataloader dangle can cause permanent
damage to the data port. It can also cause an intermittent connection,
which will result in an unsuccessful data update.
