2Map Page
The Map page displays your current flight plan overlaying a map of
the area over which you are flying. The EX5000 allows you to select
the data you want to display on the Map page.
Turn the Select knob on the Page Bar to Map to display the Map
page.
This section discusses the following topics:
l Map Page—Controls, page 8
l Map Symbols—Terrain and Position, page 16
l Map Symbols—Runways and Flight Plan, page 19
l Map Orientation Control, page 20
l Errors Displayed on the Map Page, page 21
