Data Blocks
600-00151-001 Rev 01 -103- Envision EX5000
9.7 Data Blocks
Table 9.10 Data Block Information
Name Description Range
TO WPT Name of, bearing and distance to the “To”
waypoint in the active flight plan. The
bearing is from your present position
directly to the fix. If you are off course, it
will differ from your planned course.
Distance is measured direct. Also
displays ETE (Estimated Time En route).
Note: For parallel track, there is no
waypoint label. All other data is
displayed only if supplied by GPS.
5 characters
(Name)
1 to 360 degrees
0.0 unlimited NM.
HH:MM:SS
NEXT WPT Name of, bearing and distance to the “To”
waypoint in the active flight plan.
Also displays ETE (Estimated Time En
route).
Note: For parallel track, all data is
removed.
5 characters
(Name)
1 to 360 degrees
0.0 unlimited NM.
HH:MM:SS
DEST WPT Name of and distance to the final
destination waypoint in system distance
units. Distance is measured along
planned route.
Note: For parallel track, all data is
removed.
5 characters
0.0 unlimited NM
NRST
ARPT
Identifier of, bearing and distance to the
nearest airport.
5 characters
(Name)
LAT/LON Current latitude and longitude in degrees
and decimal minutes.
N/S 0 to 90o 0’
E/W 0 to 180o 0’
BARO ALT Barometric Altitude. Based on data from
FMS (if available) or
GPS (see Note)
GND SPD Current ground speed in system speed
units.
0.0 to 999.9 knots
TRUE
AIRSPD
True Airspeed
(TAS not available from most panel-
mounted GPS systems).
From FMS
UTC TIME UTC (Greenwich or “Zulu”) time. 0 to 23h 59m 59s
LOCAL
TIME
Local data and time. Derived from UTC
time with time zone setting applied.
0 to 23h 59m 59s
Blank Blank space
