9.10 Traffic Messages
Table 9.13 Traffic Messages
Traffic Messages
& Colors
Meaning Recommended
Pilot Action
Traffic Sensor is
Operating Normally
Traffic sensor is operating
in a normal state from a
recoverable fault that was
previously acknowledged.
Acknowledge.
Traffic <Bearing> /
<Distance > /
<Relative Altitude>
Traffic Advisory Acknowledge to go to
Dedicated Traffic page
and begin looking for
traffic.
Traffic <Distance> /
<Relative Altitude>
Traffic Advisories with no
bearing information.
Acknowledge to go to
Dedicated Traffic page
to look for traffic.
Traffic <Bearing> /
<Distance>
Traffic Advisories with no
relative altitude
information.
Acknowledge to go to
Dedicated Traffic page
to look for traffic.
Traffic <Distance> Traffic Advisories with no
bearing and no relative
altitude information.
Acknowledge to go to
Dedicated Traffic page
and begin looking for
traffic.
Traffic Sensor is in
Stand- By
EX5000 receives a “Stand-
By” transmission from the
traffic sensor. Press
“Traffic” button to select a
traffic mode.
Have an Avidyne
Entegra Authorized
Service Center check
configuration and
installation if message
persists.
Traffic Sensor is in
Self-Test
Traffic sensor is in self-test
mode.
Acknowledge.
Traffic Sensor is
Not Communicating
Traffic sensor is not
transmitting data.
Have an Avidyne
Entegra Authorized
Service Center check
configuration and
installation.
