Avidyne Envision EX5000 - Table 9.16 Broadcast Datalink Messages

Reference
Envision EX5000 -116- 600-00151-001 Rev 01
Broadcast TFRs > 90
min
Broadcast TFR data age
since creation is greater
than 90 minutes. TFR
data will not display.
Monitor Broadcast
system during flight,
have system inspected
if performance does not
improve.
Broadcast Storm
Cells > 20 min
Broadcast Storm Cell
data age since creation is
greater than 20 minutes.
Storm Cells will not
display.
Monitor Broadcast
system during flight,
have system inspected
if performance does not
improve.
Broadcast Winds
Aloft > 90 min
Broadcast Winds data
age since creation is
greater than 90 minutes.
Winds data can no longer
be displayed.
Monitor Broadcast
system during flight,
have system inspected
if performance does not
improve.
Table 9.16 Broadcast Datalink Messages (Continued)
Datalink Messages
& Colors
Meaning Recommended Pilot
Action
