Assuming a 24V power supply, a Core Series Smart Hub configured with four Avigilon readers and locking
hardware uses about 2 Amps. To keep the system running for 3 hours with all entries engaged, you need 2A x 3
hours = 6AH, so two 12V 6AH sealed lead acid (SLA) or gel cell batteries wired in series.
Mounting options
Avigilon Smart Hubs use LifeSafety Power E1, E2, E3, E4, and E6 enclosures. Core Series Smart Hubs are
shipped with power supplies pre-installed, but Avigilon boards must be installed separately.
Mount the enclosure to the wall
1. (Optional) Remove the enclosure cover.
2. Locate the top keyhole mounting holes in the back of the enclosure.
3. Mark and pre-drill the locations for the keyholesin the mounting surface.
4. Partially install two fasteners appropriate for the surface on which the enclosure is being installed.
Leave the heads of the fasteners approximately ¼" out from the surface. Minimum fastener size should
be #10 or larger.
5. Hang the enclosure on the two fasteners and mark the locations of the remaining mounting holes.
6. Remove the enclosure and pre-drill the locations for the remaining mounting holes.
7. Re-hang the enclosure on the top mounting fasteners, install the remaining fasteners, and tighten all
fasteners.
8. Reinstall the enclosure's cover, if removed in step 1.
Installation 12
