Avigilon ALTA Core Series User Manual

24V FPV6
Power Supply
The main output can be switched by the Fire Alarm Interface (FAI).
Fail safe and fail secure are ways of configuring lock hardware:
l
Fail-safehardware unlocks when power is interrupted or lost.
l
Fail-securehardware locks when power is interrupted or lost.
For information about wiring third-party lock hardware, refer to vendor documentation.
Note: If locking hardware uses 12V, use the C8 Relay Based Lock Control Module. Ensure
that appropriate jumpers are set to 12V.
*OUTPUTS 1–
8
The voltage of each C8 output can be selected individually as 12V or 24V using the yellow
jumper corresponding to the output: position 1 on the jumper pins is 24V (this is the
default setting) and position 2 is 12V.
Wiring the Core Series 12/24 8-Door Large Smart Hub
The Core Series 12/24 8-Door Large Smart Hub (SYS-8ENT-DVE4)uses the LifeSafety Power FP0150to power
the Access Control Core and 8-Port Board; a LifeSafety Power B100secondary power supply; the LifeSafety
Power C8 Relay Based Lock Control Moduleto power 12-24V locking hardware; and the LifeSafety Power D8P
Power Distribution Module to power 12V and 24V locking hardware and accessories.
Installation 48
