Status LED Description
the Alta Control Center.
Center dot is solid green.
Outer ring is solid.
Reader is identified by the Alta Control Center.
Center dot is solid purple.
Outer ring is solid white.
Reader might not be receiving enough voltage or
current, potentially due to a break in wiring. Try
connecting the reader directly to the ACU, bypassing
any wire runs.
Center dot is solid pink.
Outer ring is solid white.
Check that +12V IN (orange) is not swapped with +B
(blue) or -A (violet).
Avigilon Pro Series Reader LEDs
The Video Reader Pro and Video Intercom Reader Pro status LEDsindicate the following:
Status LED Description
Center dot is solid white. Entry is locked.
Outer ring is solid white Entry is unlocked.
All lights are off. Reader is not connected to power. Check to see if power wires
are swapped.
Center dot is flashing blue. Device is booting.
Center dot is solid yellow. Device is restoring software to factory default.
Center dot is solid blue. Reader is ready to be provisioned or has not been configured as
an entry in the Alta Control Center.
Center dot is solid purple. Reader is ready to connect to Open Admin app.
Center dot is solid green
and the outer ring is solid
white.
Reader has been identified via the Alta Control Center.
Provisioning ACUs 60
