Electrical specifications
For the hardware specifications, see the datasheets on page9.
16 I/O Elevator Board (OP-16EM) 12-24VDC, 0.35A @ 12V, 0.2A @ 24V
4-Port Board (OP-EX-4E) 12-24VDC, 0.5A @ 12V, 0.3A @ 24V
8-Port Board (OP-EX-8E) 12-24VDC, 0.6A @ 12V, 0.3A @ 24V
Smart Reader v2 (OP-R2X-STND, OP-R2X-
MULL)
12-24VDC, 0.25A @ 12V, 0.12A @ 24V
Embedded USB Smart Reader (OP-R2X-
EMBD)
12-24VDC, 0.25A @ 12V, 0.12A @ 24V, 5V USB
Smart Keypad Reader (OP-RKP-STND, OP-
RKP-MULL)
12-24VDC, 0.25A @ 12V, 0.12A @ 24V
Access Control Core (OP-ACC) Operating Voltage: 12-24VDC
Operating Current: 0.7A @ 12VDC, 0.4A @ 24VDC
Access Control Core (OP-CR-ACC) Operating Voltage: 12-24VDC
Operating Current: 0.7A @ 12VDC, 0.4A @ 24VDC
Video Intercom Reader Pro (OP-VID-PRO-
INT)
Input Voltage: 802.3af PoE (48VDC)
Power Consumption: 10.8W
Video Reader Pro (OP-VID-PRO-RDR) Input Voltage:802.3af PoE (48VDC)
Power Consumption: 7.8W
Core Series 12/24V 4-Door Smart Hub
(SYS-4ENT-DVE1)
Input Voltage: 120VAC, 208/230VAC with cuttable jumper
Input Current: 1.8Amp max.
Operating Voltage: 12VDC and 24VDC
Operating Current: 1.2A @ 24V with 4 Smart Readers, 0.7A @
24V with no Smart Readers
Core Series 12/24V 8-Door Smart Hub
(SYS-8ENT-DVE2)
Input Voltage: 120VAC, 208/230VAC with cuttable jumper
Input Current: 3.7Amp max.
Operating Voltage: 12VDC and 24VDC
