Install the Video Reader Pro
The Video Reader Pro combines a built-in high-resolution camera with the form factor of a mullion door reader.
The video readers are powered using PoE and do not need to be wired back to an Avigilon ACU. However, you
must use an ACUor third-party panel to support locking hardware.
Specifications
For the Video Reader Pro specifications and dimensions, see the OP-VID-PRO-RDR datasheet.
Prerequisites
Create the video reader in the Alta Control Center prior to installing and provisioning. For more information, see
the Avigilon Alta Control Center Administrator Guide. See also Network security best practices on page38.
To install the Mobile Gateway option, see the Installation article.
Installation
You can install the Video Reader Pro on a narrow surface using the mullion mount or on a single gang box using
the standard mount.
Install the Video Reader Pro on the mullion mount
1. Use the provided machine screws (a) in threaded holes, or the wall mount screws and anchors (not
shown) for drywall, to attach the mullion mounting plate (b) to the wall.
2. Place the cradle bracket (c) on the mounting plate, angled as desired, and secure with the provided
screws (d).
3. Wire and provision the device. See the provisioning reader topic on the next pages.
4. Snap in the reader (e), and secure with the security set screw (f).
Note: Do not use adhesive.
Installation 34
