Connector type Description
USB 2.0 Micro B Connect to host over USB for keyboard emulation
Short name Full name
GND Ground (RTN)
+B RS485-B
-A RS485-A
VIN +12V IN
Table 4 Connections from Avigilon ACU to Avigilon Embedded reader
Short name Full name
VO Wiegand Voltage
GND Wiegand RTN
WD0 Wiegand Data 0
WD1 Wiegand Data 1
LED Wiegand LED
BUZZER Wiegand Buzzer
Table 5 Connections to third-party Wiegand reader (optional)
Temperature must not exceed -22°F to 140°F (-30°C to 60°C).
Installation 33
