3. If mounting the Access Control Core without the bracket, see Install Access Control Core without
mounting bracket on page13. Ensure the Ethernet and USBports face left.
If mounting the Access Control Core with the bracket, see Install Access Control Core with mounting
bracket on page14. Ensure the Ethernet and USB ports face right.
4. Connect the Access Control Core to the 16 I/O Elevator Board with the included USB cable.
Note: The maximum recommended USB cable lengthis 6 feet (2 meters) or 10 feet (3 meters) if high
quality, shielded cable.
Installation 17
