15
General
F-FEM-CON — Users Guide
2 General
2.1 Performance Data
The F-FEM-CON (Fast Front End Module Controller) was designed to meet the
growing demands of modern data acquisition. The F-FEM-CON offers a broad
range of performance features, with respect to data acquisition rate, accuracy,
resolution, etc. Furthermore, the installation effort for the F-FEM-CON is rela-
tively low compared to other data acquisition systems.
The main application of the F-FEM-CON is in the area of engine test beds, as
well as in all types of vehicle testing.
3 interfaces for IEEE1394
2 SUB-D sockets for the connection of the following sensors:
Digital inputs (digital pick-up): 1 or 2 phases;
electrically isolated from system and from other channels.
Inductive pick-up: 1 phase, electrically isolated from system
Incremental rotary encoder RS422:
1 or 2 phases, with reference point processing (3-track);
5 V encoder supply;
electrically isolated from system, connected to digital GND.
Hall speed encoder: 1 or 2 phases
4 independent counter channels for data acquisition
18 digital inputs
26 digital outputs
4 analog inputs
1 analog input for strain gauge
4 analog outputs
2 frequency outputs
1 watchdog function for test bed monitoring
Connection of 2 F-FEM-DIO modules with 16 digital inputs and 16 digital
outputs each
CAN 2.0 B interface (only for F-FEM-CON Advanced)
