Inst
allation
22
F-FEM-CON
— User
’
s Guide
3.2 Mechanical
Installation
3.2.1
External Dimensions, Space Requirement
The required mounting
space on the mounting pan
el is 1
10 mm x 264 mm. The
mounting depth is 180 mm. With th
e plugs connected it is 245 mm.
Fig.
5
W = 110
H
=
2
6
4
H
/
2
=
1
3
2
245
D = 180
21
23
