AVL F-FEM-CON User Manual

43
Operation
F-FEM-CON — User’s Guide
4.1.4.2 Current
Without Isolation With Isolation
Measuring range +
25 mA min.
Nominal range +
20 mA
No Missing Codes 24 bit
Integral Nonlinearity +
0.0015 % typ. @ T
a
= 25 °C
+
0.0075 % max.
Accuracy
at T
a
= 25 °C (+ 5°C)
2.5 μA typ. 5 μA typ. 7.5 μA typ. 12 μA typ.
Accuracy
at T
a
= 0 to 60 °C
6 μA typ. 9 μA typ. 10 μA typ. 16 μA typ.
Sampling Rates Resolution
≤ 100 Hz 20 bit
200 Hz 18 bit
500 Hz 17 bit
1000 Hz 16 bit
Common Mode Range +
9 V max.
Input Resistance 500 Ω
Sampling Rates 1 Hz – 1000 Hz
Tab. 4
NOTICE
All specifications are for T
a
= 0 to 60 °C unless otherwise noted.
All values of discrepancy refer to the nominal range +
10 V.

AVL F-FEM-CON Specifications

General

Brand	AVL
Model	F-FEM-CON
Category	Measuring Instruments
Language	English
