55
Operation
F-FEM-CON — Users Guide
4.6.2
Input Circuit for Inductive Pick-up
The pin assignment above applies to X17 and X18.
4.6.3
Input Circuit for Incremental Rotary Encoder
The pin assignment above applies to X17 and X18.
Fig. 30
Inductive 1-
X17/5
X17/17
Inductive 1+
to
internal logic
56 k2.7k
2.7k
1
56 k
2.7 k
2.7 k
Fig. 31
