AVL F-FEM-CON User Manual

Operation
48
F-FEM-CON — User’s Guide
4.3.2 Specifications
4.3.2.1 Voltage Output
4.3.2.2 Current Output
Quantity Min. Typ. Max. Unit Remark
Output Voltage Range +
10.5 + 11 V
Resolution 335 μV16 bit
Integral Nonlinearity +
1.3 mV ± 4 LSB
Differential Nonlinearity +
168 μV±0.5 LSB
Gain Error: Adjustment with a
load of 10 GΩ
+
0.5 + 1mVat 25 °C
Gain Drift +
20 + 62 μV/K
Offset Error: Adjustment with
a load of 10 GΩ
+
1mVat 25 °C
Offset Drift +
6+14 μV/K
Total Accuracy 1 3.3 mV at 25 °C
2 4.6 mV from 0 to 60 °C
Output Current +
10 mA permanently short
circuit-proof
Load Capacity 100 nF
Output Bandwidth 10 kHz
Output Noise 250 μV
RMS
0.1 Hz to 1 MHz
Output Resistance 500 mΩ
Tab. 6
Quantity Min. Typ. Max. Unit Remark
Output Voltage Range +
21 + 22 mA
Resolution 673 nA 16 bit
Integral Nonlinearity +
2.6 μA+4 LSB
Differential Nonlinearity +
381 nA + 0.5 LSB
Gain Error: Adjustment with a
load of 1 Ω
+
2.5 μAat 25 °C
Gain Drift +
20 + 250 nA/K
Offset Error: Adjustment with
a load of 1 Ω
+
2 μAat 25 °C
Offset Drift +
20 + 60 nA/K
Total Accuracy 2.5 7.1 μAat 25 °C
6.3 18.6 μA from 0 to 60 °C
Voltage at the load +
11 V I
out
= 20 mA
Load Inductivity 100 μH at a load of 500 Ω
Output Bandwidth 10 kHz
Output Noise 10 μA
RMS
0.1 Hz to 1 MHz
Tab. 7
