Appendix
F-FEM-CON — User’s Guide
6 Appendix
6.1 Technical Data
*) Only for F-FEM-CON Advanced
Case: 110 mm x 264 mm (6 HU) x 180 mm (width x height x depth)
Supply voltage: 24 V DC +
20 %
Reverse battery protection provided
Power consumption: 18 watt (typical)
46 watt (max)
Ambient temperature: 0 to 60 °C
Storing temperature: -20 to 85 °C
Relative humidity for storage: 0 to 90 %
Relative humidity for operation: 20 to 80 %, no condensation
Operating altitude: 3000 m max. above sea level
Number of channels: 2 sensor sockets with 4 signal conditionings each
4 counter channels
18 digital inputs
26 digital outputs
4 analog inputs
1 analog input for a Load Cell
4 analog outputs
2 frequency outputs
1 watchdog
Interfaces: 3 x IEEE1394
2 x Add-on
1 CAN 2.0B *)
Cable lengths: IEEE1394 max. 10 m, for longer cables: repeater
Add-on max. 15 m
Weight: 1.99 kg
