Page #88 background imageLoading...
Page #88 background image
Operation
88
F-FEM-CON — Users Guide
4.12.4
Analog Outputs X5 ... X8
Fig. 61
Pin Signal at X5 Signal at X6
1 Uout1– Uout2–
2 Uout1+ Uout2+
3 Iout1+ Iout2+
4 Iout1– Iout2–
5 AOGND_1 (opt.) AOGND_2 (opt.)
6nc nc
7 Shielding (opt.) Shielding (opt.)
8nc nc
9DGND DGND
Case Shielding Shielding
Tab. 23
Pin Signal at X7 Signal at X8
1 Uout3– Uout4–
2 Uout3+ Uout4+
3 Iout3+ Iout4+
4 Iout3– Iout4–
5 AOGND_3 (opt.) AOGND_4 (opt.)
6nc nc
7 Shielding (opt.) Shielding (opt.)
8nc nc
9DGND DGND
Case Shielding Shielding
Tab. 24
