AVL F-FEM-CON User Manual

53
Operation
F-FEM-CON — User’s Guide
4.5.2 Specifications
*) valid for F-FEM-CON Advanced
Measured Quantity Min Typical Max Unit
Operating voltage, reverse battery
protected
6 2445V
Switching current for resistive load 70 mA
Operating frequency 250
500 *)
Hz
Hz
Inductive load dump voltage -56 V
Leakage current 10 μA
Short circuit current, internally
limited
1.2 Α
ON resistance 4 Ω
Inductive load at rated current 1.5 H
Update rate of PUMA Open 2
1 *)
ms
ms
Delay time PUMA Open (1.2, 1.3)
to output
2.5 3.5 ms
Tab. 10
NOTICE
All specifications are for an ambient temperature between 0 and 60 °C and a
supply voltage of 24 V +
20 % unless otherwise noted.
