F-FEM-CON — User’s Guide
4.10.1
Seven-Segment Display
The seven-segment display shows the F-FEM number, according to paramete-
rization.
If errors occur, error numbers will be displayed (e.g. E1, E2, ...).
The table below gives an overview of the numbers displayed:
Display Function Description, Remedy
. . Hardware reset Is shown briefly when the module is started (for approx. 2 - 3 sec).
Intermittently flashing dots indicate a hardware fault. Please send the device
in for repair!
Bl Boot-Load A new firmware is being transferred.
Fl Flash The new firmware is being stored in the permanent memory (Flash EPROM).
This takes approx. 15 seconds. During this time, the power supply must not
be interrupted, as otherwise an incomplete system would be created which
cannot be rebooted.
F-xxx F-FEM No. The parameterized F-FEM number of the Config table from the parameter
block FFS is displayed, dependent on the employed PUMA Open version.
E0-E9 Error The exactly meaning depends on the software version used.
Depending on the firmware used there may also be other characters that are
displayed, e. g. a scrolling text from right to the left.
S-XXX F-FEM
Serial number
It is needed with the parameterization in the Config table.
e.g.: S-123
H-XXX Hardware
Revision number
e.g.: H-350
r Root The Clockmaster is the corresponding F-FEM
Tab. 19
