AVL F-FEM-CON User Manual

45
Operation
F-FEM-CON — User’s Guide
4.2.2 Specifications
*) Since firmware Rev. 5.0.x
Conversion from value on scale (phys) into measure value (raw value in mV)
Information
From PUMA Open version 1.5 onward, it is checked, whether the input values
are within the specified range. You find the valid ranges in the F-FEM Parameter-
ization manual.
Make sure that the adjustment- and calibration points are within the valid range!
Measured quantity Min. Typ. Max. Unit Remark
Bridge resistance 125 Ω
Bridge supply voltage 5.00 V
Input voltage
between pin 1 or 9
and pin 4 or 12
7V
Bridge supply current 40 mA permanently short
circuit-proof
Bridge sensitivity 2 mV/V
Measuring range (Raw value) +
20
+
10
+
5
+
2.5
mV Gain = 200
400
800
1600
Measuring range (phys.
value)
+
800
Integral nonlinearity +
0.0015 0.0075 %
Total error (inclus. zero, gain
and temperature effect)
+
0.005
+
0.015
+
0.15
%
%
%
20 °C ... 30 °C
20 °C ... 40 °C
0 °C ... 60 °C
Input resistance
between pin 1 or 9
and pin 4 or 12
20 MΩ
Resolution 24 Bit
Temperature coefficient
Typ. value refer to 30 ... 50 °C
Max. value refer to 0 ... 60 °C
+
0.010
+
0.018
+
0.030
+
0.050
+
0.030
+
0.040
+
0.070
+
0.140
‰ /°C Gain = 200
400
800
1600
Sample Rate 50 200 Hz *)
Cut-off frequency (-3dB)
12.0
20.0
25.0
Hz
Hz
Hz
Sample rate
50 Hz
*) 100 Hz
*) 200 Hz
Tab. 5
Raw value [mV]= Phys * 1000 / (200 * Gain)

AVL F-FEM-CON Specifications
