AVL F-FEM-CON User Manual

25
Installation
F-FEM-CON — User’s Guide
3.3.2 IEEE1394 Wiring
This section addresses particularly electrical engineers, electricians and
commissioning engineers as well as service engineers and it describes the
necessary information, the "dos and don'ts" about planning and working out the
IEEE1394 bus for an F-FEM network.
Working with the IEEE1394 cables requires basic knowledge in working with
electrical installation and cables and wires treatment.
3.3.2.1 Cable Design
*) Use this cable for module mounted close together.
**) Two adapter pieces EX0709 (0.25 m) are necessary for cables 15, 20, and
30 m (see Fig. 8):
Pcs. Required material units AVL part number
1 to 2.0 m: shielded cable 3 x 0.75 mm²
> 2.0 m: shielded cable 3 x 1.5 mm²
EX0398
EX0557
1 3-pin connector with c-clamps EU1753
1 case 9-pin EU1228
6
6
cable tube 0.75 mm²
cable tube 1.5 mm²
EP0212
EP0214
Tab. 1
NOTICE
Due to the high-speed data transfer on the IEEE1394 bus the wiring must be
done with appropriate care!
NOTICE
For wiring the IEEE1394 bus on the AVL F-FEM, please only use the special
cables! (See Tab. 2 on page 25.)
Other cables from other manufacturers or office supply or multimedia stores
must not be used, as these would lead to various network problems!
Length AVL part number
0.35 m EX1216 *)
0.7 m EX0532
1 m EX0555
2 m EX0533
4.5 m EX0534
5 m EX1037
15 m EX0715 **)
20 m EX0716 **)
30 m EX0717 **)
Tab. 2
